Guide to Installing Yamaha YXZ LED Chase Lights

If you're an off-road enthusiast, you know how important visibility and safety are, especially when navigating dusty trails or riding at night. Installing Yamaha YXZ LED Chase Lights by RLB Motorsports is one of the best upgrades you can make to your UTV. These lights not only enhance your vehicle's visibility but also improve communication with fellow riders, making your adventures safer and more enjoyable.



In this guide, we’ll walk you through the installation process of RLB’s LED Chase Lights step by step. Whether you’re a seasoned rider or new to off-roading, this guide will help you get your chase lights up and running in no time.



Shop Yamaha YXZ LED Chase Lights Now



Why Install Yamaha YXZ LED Chase Lights?



Before diving into the installation process, let’s talk about why these lights are a game-changer for your Yamaha YXZ.



1. Enhanced Safety

RLB Motorsports’ LED Chase Lights are designed to make your UTV visible in low-visibility conditions like dust, fog, or nighttime rides. With features like multiple color options (amber, white, red, green, and blue) and programmable patterns, these lights ensure that other riders can see you clearly.



2. Easy Installation

Thanks to RLB’s 100% plug-and-play design, installing these lights is straightforward. The included GM Style Deutsche connectors eliminate the need for wire cutting or crimping.



3. Durability



Built with waterproof and impact-resistant materials, these lights can withstand harsh off-road conditions. Whether you're riding through mud or rocky terrain, RLB’s chase lights are built to last.



Tools You’ll Need for Installation



Here’s a quick checklist of tools and equipment you’ll need:

• Screwdriver set
• Adjustable wrench
• Zip ties (for securing wires)
• Measuring tape
• Drill (optional for custom mounting)
• Inline fuse (recommended for added safety)
• Power distribution block (optional for multiple accessories)



Step-by-Step Installation Guide



Step 1: Choose the Mounting Location



The ideal spot for mounting your chase light is on the rear roll cage or roofline of your Yamaha YXZ. This ensures maximum visibility for riders behind you.



• Use a measuring tape to center the light bar on the roll cage.
• Mark the mounting points with a pencil or marker.

Step 2: Attach the Mounting Brackets



Secure the mounting brackets to the chosen location using the provided hardware. Ensure that the brackets are tightly fastened to prevent vibrations during rides.



Pro Tip: Use rubber isolators between the brackets and roll cage to minimize vibrations and protect the paint.



Step 3: Connect the Wiring



1. Locate your Yamaha YXZ’s power source (battery or fuse box).
2. Connect the chase light’s positive wire to the battery’s positive terminal.
3. Attach the negative wire to a grounding point on your UTV.
4. If using an inline fuse, install it between the positive wire and battery terminal for added protection.

Optional: For multiple accessories, use a power distribution block to organize wiring neatly.



Step 4: Secure the Wires



Run the wires along the roll cage or frame of your Yamaha YXZ. Use zip ties to secure them in place and prevent them from dangling or getting caught during rides.



Step 5: Test Your Lights



Before hitting the trails, test your chase lights:

• Turn on your UTV’s ignition.
• Cycle through different light patterns and colors using the control switch.
• Adjust alignment if necessary to ensure optimal visibility without blinding other riders.



Installation Tips for Best Results



To ensure a smooth installation process and long-lasting performance:



1. Use Weatherproof Wiring: Off-road conditions can be harsh, so invest in high-quality weatherproof wiring to prevent electrical issues.
2. Align Properly: Make sure your lights are aligned correctly to maximize visibility while avoiding glare for other riders.
3. Secure Mounting: Double-check that all screws and brackets are tightly fastened.
4. Accessible Controls: Install the control switch in a location that’s easy to reach while driving.



These features ensure that you get maximum performance and reliability from your Yamaha YXZ LED Chase Lights.



Why Choose RLB Motorsports?



RLB Motorsports has been a trusted name in off-road lighting since 2014. Their commitment to quality and innovation has made them a leader in LED chase lights for UTVs like Yamaha YXZ. Here’s what sets them apart:



• Plug-and-Play Design: No complicated wiring required.
• Durability: Built to withstand extreme off-road conditions.
• Customer Support: Friendly staff and technical support available.
• Limited Lifetime Warranty: Peace of mind with every purchase.



Discover Our Best Yamaha YXZ LED Chase Lights for Off-Road Safety - RLB Motorsports



Yamaha YXZ LED Chase Light – Dual Color (GREEN/WHITE) RLB Motorsports




Description (Yamaha YXZ LED Chase Light – Dual Color (GREEN/WHITE) RLB Motorsports):



Product Features: Dual LED Color Configuration:



• Primary: Green with multiple lighting modes • Solid green illumination • 6 distinct green strobe patterns
• Secondary: White functionality • Solid white for cargo/reverse lighting • 2 permanent amber center LEDs



Integrated 36" Rear Light Bar:



• Built-in red LED running lights
• Brake light functionality
• Compatible with all blinker kits



Installation Benefits:



• Complete plug-and-play system
• Includes Yamaha YXZ-specific pigtail
• Premium GM-style Deutsche connectors
• Zero wire cutting or crimping needed
• Direct connection to compatible pigtail



Yamaha YXZ LED Chase Light – San Felipe (Amber/White) RLB Motorsports

Description (Yamaha YXZ LED Chase Light – San Felipe (Amber/White) RLB Motorsports):



Product Features: Advanced Lighting Configuration:



• Dual amber LED dust lights
• Independently controlled center WHITE LED lights • Reverse/cargo illumination • Three-position rocker switch included • Custom ON/OFF functionality



Integrated 36" Rear Light Bar:



• Built-in red LED running lights
• Brake light functionality
• Compatible with all blinker kits



Installation Benefits:



• Complete plug-and-play system
• Includes Yamaha YXZ-specific pigtail
• Premium GM-style Deutsche connectors
• Zero wire cutting or crimping needed
• Direct connection to compatible pigtail



Engineered specifically for the Yamaha YXZ platform, this San Felipe edition combines practical visibility features with user-friendly controls, making it ideal for both recreational and competitive off-road use.



Dual 6″ Chase Lights – Tecate Split RLB Motorsports









Description (Dual 6″ Chase Lights – Tecate Split RLB Motorsports):



Product Features: Premium Lens Technology:



• Proprietary titanium-coated lens design
• Chrome-like illuminated reflection
• Sleek stealth titanium finish



Dual Light Bar Configuration:



• Two synchronized 6" chase light bars
• Advanced color-switching capability • Amber dust lights with multiple patterns • Automatic red brake light conversion • Optional amber-only operation mode
• Synchronized pattern control across both units



Perfect Split Configuration:



• Ideal for UTVs with: • Rear-mounted tire racks • Custom bumpers • Audio systems • Other center-mounted accessories



Installation Benefits:



• Universal UTV compatibility
• Complete plug-and-play system
• Premium GM-style Deutsche connectors
• Zero wire cutting or crimping needed
• Direct connection to compatible pigtails



Engineered for versatility and style, this split chase light system offers a sophisticated solution for vehicles where traditional single-piece light bars aren't practical, without compromising on visibility or functionality.
